ISO 15 6200 Series Deep Groove Ball Bearings Specification
What ISO 15 fixes, what it deliberately leaves to another document, its equivalents, and the dimensional table.
ISO 15 fixes the boundary dimensions of metric radial rolling bearings: the bore d, the outside diameter D, the width B and the limiting corner radius r, arranged in diameter and width series so that a bore of 20 mm exists in several standard envelopes (6004, 6204, 6304, 6404). It is the reason a 6204 from any manufacturer drops into the same housing.
Standard
ISO 15
Covers
Boundary dimensions of radial rolling bearings
Does not fix
It says nothing about how much load the bearing carries, how fast it may run, how accurately it is made or how much clearance it has. Load ratings are calculated to ISO 281, running accuracy is ISO 492 and radial internal clearance is ISO 5753-1.
Equivalents
DIN 616 restates the dimension plan nationally, with the individual bearing types in DIN 625, DIN 628, DIN 630, DIN 635 and DIN 5412; GB/T 273.3 carries the same plan in China.
Product
6200 Series Deep Groove Ball Bearings
Governing standards
ISO 15 / DIN 625-1 / GB/T 276
Equivalence between the ISO, DIN and GB/T documents is dimensional: a bearing made to either mounts in the same seat. It is not an equivalence of load rating, tolerance class or internal clearance, each of which is fixed by a separate standard and declared separately.
For 6200 series deep groove ball bearings, ISO 15 is one of the controlling documents. The sections below describe its scope, the properties it does NOT decide and which standard does decide them, the equivalent designations, and the full size range.
ISO 15 — Scope
ISO 15 fixes the boundary dimensions of metric radial rolling bearings: the bore d, the outside diameter D, the width B and the limiting corner radius r, arranged in diameter and width series so that a bore of 20 mm exists in several standard envelopes (6004, 6204, 6304, 6404). It is the reason a 6204 from any manufacturer drops into the same housing.
What ISO 15 Does Not Fix
It says nothing about how much load the bearing carries, how fast it may run, how accurately it is made or how much clearance it has. Load ratings are calculated to ISO 281, running accuracy is ISO 492 and radial internal clearance is ISO 5753-1.
This division of labour is the thing to carry away from any bearing standard. A boundary dimension standard makes bearings interchangeable; it does not make them equivalent. Two bearings of the same designation from different makers mount in the same seat and are not required to have the same load rating, the same internal design, the same cage or the same speed limit.
Dimensions Supplied to ISO 15
Designation
Bore d (mm)
Outer diameter D (mm)
Width B (mm)
Chamfer r min (mm)
Basic dynamic load rating Cr (kN)
Basic static load rating C0r (kN)
Limiting speed grease (rpm)
Mass (kg)
6200
10
30
9
0.6
5.07
2.36
19000
0.032
6201
12
32
10
0.6
6.89
3.10
17000
0.037
6202
15
35
11
0.6
7.80
3.75
15000
0.045
6203
17
40
12
0.6
9.95
4.75
13000
0.065
6204
20
47
14
1
13.5
6.55
11000
0.106
6205
25
52
15
1
14.8
7.80
9500
0.128
6206
30
62
16
1
20.3
11.2
8500
0.200
6207
35
72
17
1.1
25.5
15.3
7000
0.288
6208
40
80
18
1.1
30.7
19.0
6300
0.368
6209
45
85
19
1.1
33.2
21.6
6000
0.414
6210
50
90
20
1.1
35.1
23.2
5600
0.462
6211
55
100
21
1.5
43.6
29.0
5000
0.603
6212
60
110
22
1.5
47.5
32.5
4500
0.780
6213
65
120
23
1.5
55.9
40.5
4300
0.990
6214
70
125
24
1.5
61.8
45.0
4000
1.05
6215
75
130
25
1.5
66.3
49.0
3800
1.20
6216
80
140
26
2
72.8
55.0
3600
1.40
6217
85
150
28
2
83.2
64.0
3400
1.80
6218
90
160
30
2
95.6
73.5
3200
2.15
6219
95
170
32
2.1
108
83.0
3000
2.60
6220
100
180
34
2.1
124
93.0
2800
3.20
Catalog Products Governed by ISO 15
ISO 15 governs more than this one series. In this catalog it applies to:
ISO 15 is the international reference and the right one to cite on a new drawing or a purchase specification. Adding the national equivalents alongside it costs nothing and makes the requirement legible to a supplier working to DIN or to GB/T.
Other ways to specify the 6200 Series Deep Groove Ball Bearings
The same part is also governed by DIN 625 and GB/T 276, and where two standards cover one dimension they agree — the numbers are the same, the document is not.
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the designation snaps the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Our facility
Where these dimensions are actually made
Ring forging, heat treatment, raceway grinding and superfinishing all happen under one roof, so a bore tolerance and a clearance group are set by processes we control and can evidence, not by whichever supplier had stock.
Request a Quote
The form below follows the current technical drawing configuration. Change the drawing values above and the request details update automatically.
Dimensions & Specifications (ISO 15 / DIN 625-1 / GB/T 276)
Designation
Bore d (mm)
Outer diameter D (mm)
Width B (mm)
Chamfer r min (mm)
Basic dynamic load rating Cr (kN)
Basic static load rating C0r (kN)
Limiting speed grease (rpm)
Mass (kg)
6200
10
30
9
0.6
5.07
2.36
19000
0.032
6201
12
32
10
0.6
6.89
3.10
17000
0.037
6202
15
35
11
0.6
7.80
3.75
15000
0.045
6203
17
40
12
0.6
9.95
4.75
13000
0.065
6204
20
47
14
1
13.5
6.55
11000
0.106
6205
25
52
15
1
14.8
7.80
9500
0.128
6206
30
62
16
1
20.3
11.2
8500
0.200
6207
35
72
17
1.1
25.5
15.3
7000
0.288
6208
40
80
18
1.1
30.7
19.0
6300
0.368
6209
45
85
19
1.1
33.2
21.6
6000
0.414
6210
50
90
20
1.1
35.1
23.2
5600
0.462
6211
55
100
21
1.5
43.6
29.0
5000
0.603
6212
60
110
22
1.5
47.5
32.5
4500
0.780
6213
65
120
23
1.5
55.9
40.5
4300
0.990
6214
70
125
24
1.5
61.8
45.0
4000
1.05
6215
75
130
25
1.5
66.3
49.0
3800
1.20
6216
80
140
26
2
72.8
55.0
3600
1.40
6217
85
150
28
2
83.2
64.0
3400
1.80
6218
90
160
30
2
95.6
73.5
3200
2.15
6219
95
170
32
2.1
108
83.0
3000
2.60
6220
100
180
34
2.1
124
93.0
2800
3.20
Video: ISO 15 6200 Series Deep Groove Ball Bearings Specification
Third-party video, selected automatically for this topic. It is not produced by Bushing Bearings and is not a specification source — use the tables on this page for dimensional data.
Frequently Asked Questions
Which edition of ISO 15 does this table follow?
The table reproduces the dimensions we supply 6200 series deep groove ball bearings to. We do not publish an edition year against it, so where the edition is contractually significant, cite the edition you require on the enquiry and we will confirm it against the table before quoting.
Can I cite the GB/T number instead of the ISO one?
For the boundary dimensions, yes — the GB/T standards restate the ISO dimension plan and a part made to either mounts in the same seat. The safest drawing note gives both, because it stays legible if the supply moves between a Chinese, a European and an international manufacturer.
What does ISO 15 specify?
ISO 15 fixes the boundary dimensions of metric radial rolling bearings: the bore d, the outside diameter D, the width B and the limiting corner radius r, arranged in diameter and width series so that a bore of 20 mm exists in several standard envelopes (6004, 6204, 6304, 6404). It is the reason a 6204 from any manufacturer drops into the same housing.
What does ISO 15 not cover?
It says nothing about how much load the bearing carries, how fast it may run, how accurately it is made or how much clearance it has. Load ratings are calculated to ISO 281, running accuracy is ISO 492 and radial internal clearance is ISO 5753-1.
How do I request a quotation?
Use the technical drawing on this page to pick the exact configuration, then submit it with the quote form. We respond within one business day.
